Secure Shell (SSH)

Here you will find an SSH configuring and hardening guide.

Installation

apt install openssh-server openssh-client

Usage

Server:

systemctl enable sshd.service
systemctl ( start | stop | restart ) sshd.service

Client:

ssh [options] user@host [command]

Common options

parameter	description
-p	port number, if you changed the standard port
-i	alternative identify file, like ~/.ssh/id_ed25519.pub
-j	ProxyJump-Host, like user@host, if you want to connect to an otherwise unreachable host
-Y	X11-Forwarding of graphical apps through ssh

Generating ssh keys

ssh-keygen -t ed25519 -a 100 -f ~/.ssh/id_ed25519_pq

This private/public key pair will be created in your home folder, ~/.ssh. You will also be asked if you want to set a password for your key pair. This is used for every “new” use of this key pair to decrypt it. This key is post-quantum save.

Copy id to ssh-client for authentication

The following command will copy all generated public keys to a host you want to authenticate without password.

ssh-copy-id user@host

It is also possible to define options like if you need to make use of ProxyJump-host or define a specific id.

ssh-copy-id -i ~/.ssh/id_ed25519.pub -o "ProxyJump <host or ip>" user@host

Server configuration (Example)

Usually you’ll find the configuration file in /etc/ssh/sshd_config. Keep an eye on sshd not ssh.

# OpenSSH sshd_config
# Profile: ECC-only identities + Post-Quantum hybrid KEX
# Requires: OpenSSH >= 9.0 (tested with 10.0p1)

# Network
Port 22
AddressFamily inet
ListenAddress 192.168.0.4

# Host Keys (ECC only)
HostKey /etc/ssh/ssh_host_ed25519_key
HostKeyAlgorithms ssh-ed25519

# Key Exchange (Post-Quantum Hybrid ONLY)
KexAlgorithms sntrup761x25519-sha512@openssh.com

# Symmetric Crypto (AEAD only)
Ciphers chacha20-poly1305@openssh.com,aes256-gcm@openssh.com

# MACs not used with AEAD ciphers

# Authentication
PermitRootLogin no
PasswordAuthentication no
KbdInteractiveAuthentication no
UsePAM no
PubkeyAuthentication yes

# User keys: ECC only
PubkeyAcceptedKeyTypes ssh-ed25519

# Authorization scope
# AllowUsers <DEIN_USER>

# Session hardening
LoginGraceTime 30s
MaxAuthTries 2
MaxSessions 3

ClientAliveInterval 300
ClientAliveCountMax 1

# Channel restrictions
AllowAgentForwarding no
AllowTcpForwarding no
GatewayPorts no
X11Forwarding no
PermitTunnel no

# Environment
PermitUserEnvironment no
AcceptEnv LANG LC_*

# Logging
SyslogFacility AUTH
LogLevel VERBOSE

# Misc
TCPKeepAlive yes
PrintMotd no
Banner none
VersionAddendum none

# Subsystems
Subsystem sftp internal-sftp

value	description
Port < xx >	Specifies another port to be used by SSH. Default: 22
AddressFamily	Setting: any / inet / inet6, inet=IPv4, inet6=IPv6
ListenAddress	Specifies the IP of the interface SSH should only listen on.
PubKeyAuthentication	yes/no, Turn on/off authentication with key pairs.
AuthorizedKeyFile	Location of authorized key collection file
PermitRootLogin	yes/no, prohibit-password means password authentication is disabled but authentication with key pair is till possible
X11Forwarding	yes/no, if you want to access graphical applications through ssh
AllowTcpForwarding	Allow “ProxyJump”-ing on this host

Client configuration (Example)

Therefore you have to create a file called ~/.ssh/config in your home directory.

Host ssh-proxy
        User root
        Hostname 172.16.0.2
        Port 2222
Host dhcp-server
        User root
        Hostname 10.11.12.2
        Port 2222
        ProxyJump ssh-proxy

value	description
Host < hostname >	This keyword defines defines the “short word” to connect to your clients.
User < username >	The user you want to connect with on the host.
Hostname < IP >	Specifies th IP address you want to connect to.
Port < Port >	Specifies the port you want to connect to in case you’ve changed it.
ProxyJump < IP or Host >	If you have to connect to a host which is not directly accessible, but with a “jump” from another host.

ssh dhcp-server

You’re also able to modify the command, e.g. you want to connect on the wanted machine with another user.

ssh user@dhcp-server

Secure Copy (SCP)

Secure-Copy allows file duplication over SSH.

Usage

scp -i ~/.ssh/id_ed25519.pub -J firewall -P 222 source_file user@server:/path/to/destination

As you see the same options as in ssh are available.

Secure File Transfer Protocol (SFTP)

Secure File Transfer Protocol comes with the openssh-server, and for other os similar, package. It is deactivated by default and had to be configured.

Configuration

Now we add a SFTP user which is only allowed to use SFTP and nothing else. Therefor create a new group called sftponly

groupadd sftponly

mkdir -pv /srv/sftp/users/guest
useradd -G sftponly -d /srv/sftp/users/guest -s /bin/false guest

parameter	description
-G	Append a group to the standard groups.
-d	The home dir of the user.
-s	The given Shell, here it is nothing

At first we have to create a user share with permissions as below.

mkdir -pv /srv/sftp/share
chown root:root /srv/sftp/share
chmod 0755 /srv/sftp/share

Edit /etc/ssh/sshd_config scroll down to Subsystem sftp [...].

Subsystem sftp /usr/lib/openssh/sftp-server
UsePAM yes
Match Group sftponly
        ChrootDirectory /srv/sftp/path/to/share/%u
        ForceCommand internal-sftp
        AllowTcpForwarding no
        PasswordAuthentication yes

Usage

sftp guest@sftp-server
